A-A-55192A
3.1.Material.. The flexible/non-rigid vinyl chloride plastic film can be calendered, extruded or cast film.
The contractor shall identify the type of film used on the contract or purchase order. Film shall meet all
the requirements listed in accordance with ASTM D 1593. The zipper closure shall be made of a clear
compound of vinyl chloride or polyvinyl chloride conforming to the resin material requirements specified
in ASTM D 1593. The zipper shall have a slider and pull made of aluminum.
3.2 Finish. The film shall have a smooth, dull-matte finish on both sides unless otherwise specified by
the contract or purchase order.
3.3 Label. The case shall be labeled with the following:
Item Description
Contract Number
Stock Number
Size
Contractor's Name
The size and the characters shall be approximately ¼ inch high. A white marking medium shall be used.
The label shall be clearly legible after being subjected to the ink adhesion test. The label shall be located
midway (+/- 2 inches) between the sealed seams and the opening.
3.4 Bar Code/Label Tag. Each item shall be individually bar-coded with a paper tag, standard bleach
sulfate with a basis weight of 100 lbs. The bar code shall be a 13 digit national stock number (NSN).
The bar code shall be used with a medium to high density and shall be human-readible interpretation
(HRI). The label/tag shall be located so that it is completely visible on the item when it is completely
folded and/or packaged as specified and shall cause no damage to the item.
3.5 Sizes and Measurements. The finished case shall conform to the measurements below.
Table I. Sizes and Measurements
Size
Length
Width (inches)
Tolerance
Zipper Size
Heat Sealed
(inches)
(inches)
(inches)
Seam (inches)
+ 036,-0
1
22
30
+1, -0
22
1/8
2
38-1/2
52-3/4
+1, -0
38-1/2
l/8
2
